Zirconia material has advantages of high hardness, high strength, high tenacity, high wear resistance and good corrosion resistance which is widely applied in fields of ceramics, fire proofing material, machinery, electronic, photics, Aeronautics and astronautics, biology and chemicals and etc. Zirconia mill jar is particularly suitable for vertical stirring mill, horizontal rolling mill, vibration mill, and various high-wire-speed sanding stick pins, etc.
Hardness of zirconia: 12.3 (GPa)
Density: 6(g ▪ cm-3)
consumption resistant: 0.48(ppm/hrs)
|
Parameters of Zirconia Mill Jar |
||||||
| Volume of Jar | Inner Diameter (mm) |
External Diameter (mm) |
Inner Depth (mm) | Height Without Lid (mm) |
Total Height (mm) |
Weight (KG) |
| 50ml | 38 | 55 | 52 | 60 | 67 | 0.6 |
| 100ml | 50 | 65 | 58 | 66 | 75 | 0.8 |
| 250ml | 74 | 92 | 70 | 78 | 88 | 1.8 |
| 500ml | 84 | 100 | 100 | 108 | 118 | 2.3 |
| 1L | 108 | 128 | 128 | 138 | 148.5 | 4.7 |
| 1.5L | 112 | 132 | 155 | 165 | 175.5 | 5.5 |
| 2L | 138 | 158 | 140 | 150 | 162 | 6.9 |
| 2.5L | 138 | 158 | 170 | 180 | 192 | 7.8 |
| 3L | 138 | 158 | 198 | 208 | 220 | 8.6 |
| 4L (packaged 2mm stainless steel) | 175 | 205 | 205 | 222 | 231 | 14.8 |
| 5L (packaged 2mm stainless steel) | 170 | 192 | 228 | 240 | 254 | 16.7 |
| Remarks:1. Size deviation within ±2； 2. Weight deviation within ±0.2KG | ||||||
1. High hardness, high strength, high tenacity, high wear resistant and good corrosion resistant.
2. Strong acid resistant and alkali resistant.
3. Wear-resistant, corrosion-resistant.
4. No pollution.
5. High grinding efficiency.
6. Long life and low cost integrated.
7. Wet grinding and dispersion of occasions.
