Is designed and developed for the materials which will be oxidized easily when grinding. The good sealing performance makes it possible that materials can be separated from oxygen, water or others which will affect the grinding.
|
Specifications of Stainless Steel Vacuum Mill Jar for Planetary Ball Mill |
||||||
| Volume of Jar | Inner Diameter (mm) |
External Diameter (mm) |
Inner Depth (mm) | Height of Not Containing Cover (mm) |
Total Height (mm) |
Weight (KG) |
| 50ml | 39 | 49 | 45 | 50 | 58 | 0.7 |
| 100ml | 48 | 62 | 57 | 65 | 72 | 1.3 |
| 250ml | 73 | 88 | 65 | 73 | 80 | 2.1 |
| 500ml | 90 | 107 | 93 | 100 | 107 | 3.5 |
| 1L | 115 | 132 | 118 | 128 | 135 | 5.4 |
| 1.5L | 115 | 131 | 143 | 150 | 158 | 5.8 |
| 2L | 141 | 153 | 133 | 140 | 149 | 6.3 |
| 3L | 141 | 157 | 198 | 205 | 213 | 9.2 |
| 4L | 168 | 178 | 200 | 205 | 213 | 9.2 |
| 5L | 182 | 192 | 200 | 205 | 213 | 10.2 |
| Remarks:1. Size deviation within ±2； 2. Weight deviation within ±0.2KG | ||||||
1. Special design for the valve, convenient operation, good sealing performance.
2. Made of stainless steel, lining PU, nylon, alumina etc.
3. Factory direct sales, high cost performance.
