PTFE is abbreviation of poly tetra fluoroethylene, which is famous for “no stick coating” or “easy cleaning material”. It has advantages of acid resistance and alkali resistance. PTFE is hardly dissolved in any solvent and is often called “Plastic King” due to its features of high temperature resistance and low friction coefficient.
|
Parameters of PTFE Mill Jar |
|||
| Model | External Diameter (mm) | Inner Diameter (mm) | Height (mm) |
| 500ml | 108 | 88 | 115 |
| 1L | 133 | 109 | 142 |
| 1.5L | 133 | 109 | 178 |
| 2L | 158 | 134 | 172 |
| 2.5L | 158 | 134 | 202 |
| 3L | 158 | 138 | 210 |
| 4L | 178 | 158 | 226 |
| 5L | 218 | 190 | 217 |
| 10L | 246 | 218 | 307 |
| 15L | 273 | 243 | 372 |
| 20L | 320 | 285 | 359 |
| 25L | 320 | 285 | |
1. All PTFE roll mill jars are made of superior PTFE material which has advantages of corrosion resistance, high and low temperature resistance, low adhesion, anti-aging, good lubricant, no poison, no harm, and etc.
2. PTFE roll mill jar is made by integral informing without any chink and any gap, which benefits to avoid leakage and cracking.
3. Professional design and manufacturing, perfect matching with roll ball mill, direct sale prices, high performance price ratio.
